A fanned bristle/dry-brush effect along a path

effect_bristle() builds a group of n_bristles copies of a template drawable, fanned out perpendicular to its own backbone path.

Usage

effect_bristle(
  object,
  n_bristles = 9L,
  spread = 0.3,
  width_jitter = 0.3,
  fray = 0.15,
  jitter = 0.015,
  jitter_frequency = 1.2,
  n = 100L,
  seed = 1L
)

Arguments

object

A template pathlike drawable (@pathlike == TRUE, see drawable's docs) with a width property – typically shape_stroke(). Every bristle is a copy of object with its own fanned x/y, scaled width, and (if object has an n property) resampled n; all other properties (style, distortion, trans, ...) carry over unchanged.

n_bristles

Number of bristles to fan out. Must be a positive integer. Default 9L.

spread

Total perpendicular distance the bristles fan across, centred on the backbone. Must be non-negative. Default 0.3.

width_jitter

Fractional random variation applied to each bristle's own object@width (e.g. 0.3 scales width by a factor drawn uniformly from [0.7, 1.3]). Must be in [0, 1). Default 0.3.

fray

Maximum fraction of the backbone's own length randomly trimmed from each bristle's start and end. Must be in [0, 0.5). Default 0.15.

jitter, jitter_frequency

Passed to effect_tremor()'s own arguments of the same name, controlling each bristle's independent wobble. Defaults 0.015/1.2.

n

Number of points used along the backbone when fanning bristles out (independent of any n property object itself has). Must be at least 2. Default 100L.

seed

Integer seed for the per-bristle randomization and wobble. Default 1L.

Value

A group containing n_bristles drawables.

Details

Like effect_tremor(), no single drawable can express this by itself, since a dry-brush look comes from several independently-frayed, independently wobbling strands laid side by side, not one stroke. Each bristle is a copy of object (via S7::set_props()) that:

• is offset from the backbone by a fixed perpendicular distance (via the same per-point unit normal shape_stroke() itself uses, stroke_normals()), evenly spaced across spread;

• is trimmed to a random sub-range of the backbone's own length (fray controls how much), so bristles start/end raggedly rather than in one clean line – the same "frayed edge" a real brush's outer bristles show as it runs dry;

• has its own randomly-scaled width (via width_jitter, applied to object@width); and

• is independently wobbled via effect_tremor() (layers = 1L, since the fanning here already does the layering work effect_tremor() normally provides – one wobbling copy per bristle position, not several wobbling copies of one path).

Every other property of object – style, distortion, trans, ... – carries over to every bristle unchanged, since each is built with S7::set_props() rather than a fresh constructor call. shape_stroke()'s own taper-to-zero at both ends does double duty as each bristle's tip fade, needing no extra work here. Randomization (fray range, width scaling) is scoped per bristle with withr::with_seed(), the same reproducibility convention fill_stipple()/fill_scatter()/fill_halftone() already use, so it never leaks into the caller's global random state.

See also

Other effects: effect_grain(), effect_swatch(), effect_tremor()

Examples

t <- seq(0, 8, length.out = 200)
template <- shape_stroke(
  x = t, y = sin(t) * 1.2, width = 0.06,
  fill = "black", fill_alpha = 0.4, color = NA_character_
)

# before: a single plain stroke
draw(template)


# after: fanned into a dry-brush bristle effect
draw(effect_bristle(template, n_bristles = 11L, spread = 0.3))


# a wider spread and more fraying gives a rougher, more ragged brush
draw(effect_bristle(template, n_bristles = 15L, spread = 0.5, fray = 0.3))
