Graphical style for a drawable object

style is a container for the graphical properties passed to grid::gpar() when a drawable object is drawn.

Usage

style(
  color = "black",
  fill = fill_solid("black"),
  linewidth = 1,
  linetype = "solid",
  linejoin = "round",
  lineend = "round",
  linemitre = 10,
  rule = "evenodd",
  color_alpha = 1,
  fill_alpha = 1
)

Arguments

color: Stroke colour: a single colour string recognised by grDevices::col2rgb() (a name, "#RRGGBB"/"#RRGGBBAA" hex string, ...), or NA for a fully transparent stroke. Validated at construction time, rather than only surfacing as a grid error once draw() is called. Default "black".
fill: Fill colour or pattern. Either a plain colour string, or the output of a fill_*() helper – fill_solid(), fill_none(), fill_hatch(), fill_crosshatch(), fill_stipple(), fill_noise(), fill_gradient(), or fill_vignette(). A bare colour string/ GridPattern is coerced into a fill object automatically. Default fill_solid("black") (i.e. "black").
linewidth: Line width. Default 1.
linetype: Line dash pattern, forwarded to grid::gpar()'s lty. Either a named type ("solid", "dashed", "dotted", "dotdash", "longdash", "twodash", "blank"), an integer code 0:6, or a custom hex dash-pattern string (e.g. "13") – see grid::gpar() and graphics::par()'s lty for the full set of accepted forms, which aren't independently re-validated here. Default "solid".
linejoin: Line join style at each vertex, forwarded to grid::gpar()'s linejoin. One of "round", "mitre", or "bevel". Most visible on closed shapes with few, sharp vertices, or on any drawable stroked with a thick linewidth. Default "round".
lineend: Line end style at a path's free endpoints, forwarded to grid::gpar()'s lineend. One of "round", "butt", or "square". Only visible on "path"-geometry drawables (e.g. curve_line(), curve_bezier()) – a "polygon"-geometry drawable has no free endpoint, since its outline closes back on itself. Most visible at a thick linewidth. Default "round".
linemitre: Mitre limit, forwarded to grid::gpar()'s linemitre. Only takes effect when linejoin = "mitre": at a vertex sharper than this limit allows, the mitred corner is truncated to a bevel instead, to avoid an arbitrarily long spike. Must be at least 1. Default 10, matching grid::gpar()'s own default.
rule: Fill rule used when a drawable's own points has more than one sub-path (see xy's id), forwarded to grid::pathGrob()'s own rule argument. One of "evenodd" (default) or "winding". "evenodd" fills a region if it's enclosed by an odd number of sub-paths, regardless of each sub-path's own vertex winding direction – a sub-path nested inside another becomes a hole purely from geometric nesting, with no need to get vertex order right by hand, which is why it's the default. "winding" instead fills based on net signed winding number, which depends on each sub-path's own direction – only useful for constructions that specifically need that direction-sensitive behavior. Has no effect on a drawable with only one implicit sub-path (every current shape_*()/curve_*() constructor), since both rules agree there.
color_alpha: Stroke opacity, applied to color independently of fill_alpha. Must be a number in [0, 1], where 0 is fully transparent and 1 (the default) is fully opaque. Applied by baking the value into color via grDevices::adjustcolor() at draw time (see draw()'s internal apply_alpha() helper), not via grid::gpar()'s own alpha argument – gpar()'s alpha applies uniformly to both stroke and fill on the same grob, which would couple color_alpha and fill_alpha together. If color already has its own alpha channel (e.g. an "#RRGGBBAA" hex string), color_alpha multiplies through it rather than overriding it.
fill_alpha: Fill opacity, applied to fill independently of color_alpha, via the same grDevices::adjustcolor() mechanism as color_alpha. Must be a number in [0, 1]. Default 1. Only has an effect when fill is a plain colour string (as from fill_solid() or fill_none()) – silently inert when fill is a pattern or gradient (the output of any other fill_*() helper), since grDevices::adjustcolor() has no defined effect on a GridPattern object. This mirrors fill itself already having no effect for "path"/"points"-geometry drawables (see drawable's geometry docs), and lineend/linemitre already being inert for some geometries – geometry- or fill-type-conditional inertness, not an error, is this package's existing convention for style properties that don't universally apply.

Examples

style(color = "steelblue", fill = "lightblue", linewidth = 2)
#> <sketchpad::style>
#>  @ color      : chr "steelblue"
#>  @ fill       : <sketchpad::fill>
#>  .. @ value  : chr "lightblue"
#>  .. @ resolve: NULL
#>  @ linewidth  : num 2
#>  @ linetype   : chr "solid"
#>  @ linejoin   : chr "round"
#>  @ lineend    : chr "round"
#>  @ linemitre  : num 10
#>  @ rule       : chr "evenodd"
#>  @ color_alpha: num 1
#>  @ fill_alpha : num 1
style(fill = fill_hatch(angle = 30))
#> <sketchpad::style>
#>  @ color      : chr "black"
#>  @ fill       : <sketchpad::fill>
#>  .. @ value  :List of 9
#>  .. .. $ f     :function ()
#>  .. .. $ x     : 'simpleUnit' num 0.5npc
#>  .. ..  ..- attr(*, "unit")= int 0
#>  .. .. $ y     : 'simpleUnit' num 0.5npc
#>  .. ..  ..- attr(*, "unit")= int 0
#>  .. .. $ width : 'simpleUnit' num 0.0866npc
#>  .. ..  ..- attr(*, "unit")= int 0
#>  .. .. $ height: 'simpleUnit' num 0.05npc
#>  .. ..  ..- attr(*, "unit")= int 0
#>  .. .. $ hjust : num 0.5
#>  .. .. $ vjust : num 0.5
#>  .. .. $ extend: chr "repeat"
#>  .. .. $ group : logi TRUE
#>  .. .. - attr(*, "class")= chr [1:2] "GridTilingPattern" "GridPattern"
#>  .. @ resolve: function (aspect)
#>  @ linewidth  : num 1
#>  @ linetype   : chr "solid"
#>  @ linejoin   : chr "round"
#>  @ lineend    : chr "round"
#>  @ linemitre  : num 10
#>  @ rule       : chr "evenodd"
#>  @ color_alpha: num 1
#>  @ fill_alpha : num 1

# linejoin/linemitre are most visible on a thick-stroked shape with a
# sharp vertex
star <- shape_polygon(n = 5, radius = 1, fill = "white")
draw(shape_stroke(
  x = star@points@x, y = star@points@y, width = 0.25,
  linejoin = "mitre", linemitre = 1.5
))


# color_alpha/fill_alpha control stroke/fill opacity independently
draw(shape_circle(
  radius = 1, color = "black", fill = "tomato",
  color_alpha = 1, fill_alpha = 0.3, linewidth = 3
))


# lineend only affects a path's free endpoints, not a closed polygon
draw(curve_line(
  x = c(0, 1, 2), y = c(0, 1, 0), linewidth = 15, lineend = "square"
))
